Apem Inc. AV22PNA62
- Mfg. Part Number
- AV22PNA62
- Manufacturer
- Apem Inc.
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON SPDT 5A 250V
- Datasheet Download
- AV22PNA62.pdf
Availability of AV22PNA62
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 121.13688
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AV22PNA62, we specialize in Apem Inc. all series electronic components. AV22PNA62 can be shipped within 24 hours after order. If you have any demands for AV22PNA62, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AV22PNA62 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AV22PNA62
| Internal Part Number | EIS-AV22PNA62 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 16 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | AV | |
| Packaging | Bulk | |
| Type | Vandal Resistant | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 5A (AC) | |
| Voltage Rating - AC | 250V | |
| Voltage Rating - DC | - | |
| Actuator Type | Round, Button, Mushroom | |
| Color - Actuator/Cap | Red | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Front | |
| Termination Style | Solder Lug | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Features | Sealed - Fully | |
| Panel Cutout Dimensions | Circular - 22.20mm Dia | |
| Operating Temperature | -20°C ~ 55°C | |
| Mechanical Life | 1,000,000 Cycles | |
| Electrical Life | 100,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AV22PNA62 | |
| Related Links | AV22, AV22PNA62 Datasheet, Apem Inc. Distributor | |
AV22PNA62 Details Description
