ASSMANN WSW Components AWP14-8541-T-R
- Mfg. Part Number
- AWP14-8541-T-R
- Manufacturer
- ASSMANN WSW Components
- Product Category
- Rectangular Connectors - Free Hanging, Panel Mount
- Brief Description
- CONN SOCKET IDC 14POS W/STR TIN
- Datasheet Download
- AWP14-8541-T-R.pdf
Availability of AWP14-8541-T-R
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AWP14-8541-T-R, we specialize in ASSMANN WSW Components all series electronic components. AWP14-8541-T-R can be shipped within 24 hours after order. If you have any demands for AWP14-8541-T-R, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AWP14-8541-T-R Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AWP14-8541-T-R
| Internal Part Number | EIS-AWP14-8541-T-R | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Assmann - IDC Connectors and Cables Cable Assemblies | |
| Standard Package | 144 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Free Hanging, Panel Mount | |
| Series | - | |
| Packaging | Tray | |
| Connector Type | Socket | |
| Contact Type | Female Socket | |
| Number of Positions | 14 | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.100" (2.54mm) | |
| Mounting Type | Free Hanging (In-Line) | |
| Fastening Type | - | |
| Cable Termination | IDC | |
| Wire Type | Ribbon Cable | |
| Wire Gauge | - | |
| Features | Feed Through, Strain Relief | |
| Contact Finish | Tin | |
| Contact Finish Thickness | - | |
| Color | Gray | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AWP14-8541-T-R | |
| Related Links | AWP14-8, AWP14-8541-T-R Datasheet, ASSMANN WSW Components Distributor | |
AWP14-8541-T-R Details Description
