EPCOS (TDK) B32560J3683K
- Mfg. Part Number
- B32560J3683K
- Manufacturer
- EPCOS (TDK)
- Product Category
- Film Capacitors
- Brief Description
- CAP FILM 0.068UF 10% 250VDC 2DIP
- Datasheet Download
- B32560J3683K.pdf
Availability of B32560J3683K
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.09333
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of B32560J3683K, we specialize in EPCOS (TDK) all series electronic components. B32560J3683K can be shipped within 24 hours after order. If you have any demands for B32560J3683K, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- B32560J3683K Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
B32560J3683K
| Internal Part Number | EIS-B32560J3683K | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | B32(5679)B333 Series 02/May/2014 | |
| Standard Package | 6,800 | |
| Category | Capacitors | |
| Family | Film Capacitors | |
| Series | SilverCap™ B32560 | |
| Packaging | Bulk | |
| Capacitance | 0.068µF | |
| Tolerance | ±10% | |
| Voltage Rating - AC | 160V | |
| Voltage Rating - DC | 250V | |
| Dielectric Material | Polyester | |
| ESR (Equivalent Series Resistance) | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Mounting Type | Through Hole | |
| Package / Case | 2-DIP | |
| Size / Dimension | 0.354" L x 0.102" W (9.00mm x 2.60mm) | |
| Height - Seated (Max) | 0.224" (5.70mm) | |
| Termination | PC Pins | |
| Lead Spacing | 0.295" (7.50mm) | |
| Applications | General Purpose | |
| Features | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | B32560J3683K | |
| Related Links | B32560, B32560J3683K Datasheet, EPCOS (TDK) Distributor | |
