Omron B3F-6005-A
- Mfg. Part Number
- B3F-6005-A
- Manufacturer
- Omron
- Product Category
- Tactile Switches
- Brief Description
- SWITCH TACTILE SPST-NO 0.05A 24V
- Datasheet Download
- B3F-6005-A.pdf
Availability of B3F-6005-A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of B3F-6005-A, we specialize in Omron all series electronic components. B3F-6005-A can be shipped within 24 hours after order. If you have any demands for B3F-6005-A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- B3F-6005-A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
B3F-6005-A
| Internal Part Number | EIS-B3F-6005-A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| Standard Package | 1,750 | |
| Category | Switches | |
| Family | Tactile Switches | |
| Series | B3F | |
| Packaging | Tape & Box (TB) | |
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Contact Rating @ Voltage | 0.05A @ 24VDC | |
| Actuator Type | Standard | |
| Mounting Type | Through Hole | |
| Actuator Height off PCB, from Pins | 4.30mm | |
| Actuator Orientation | Top Actuated | |
| Termination Style | PC Pin | |
| Outline | 6.00mm x 6.00mm | |
| Illumination | Non-Illuminated | |
| Illumination Voltage (Nominal) | - | |
| Illumination Type, Color | - | |
| Operating Force | 260gf | |
| Ingress Protection | - | |
| Features | - | |
| Actuator Material | - | |
| Switch Travel | 0.25mm | |
| Mechanical Life | 100,000 Cycles | |
| Operating Temperature | -25°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | B3F-6005-A | |
| Related Links | B3F-6, B3F-6005-A Datasheet, Omron Distributor | |
B3F-6005-A Details Description
