Diodes Incorporated B550C-13
- Mfg. Part Number
- B550C-13
- Manufacturer
- Diodes Incorporated
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE SCHOTTKY 50V 5A SMC
- Datasheet Download
- B550C-13.pdf
Availability of B550C-13
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of B550C-13, we specialize in Diodes Incorporated all series electronic components. B550C-13 can be shipped within 24 hours after order. If you have any demands for B550C-13, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- B550C-13 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
B550C-13
| Internal Part Number | EIS-B550C-13 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 50V | |
| Current - Average Rectified (Io) | 5A | |
| Voltage - Forward (Vf) (Max) @ If | 700mV @ 5A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 500µA @ 50V | |
| Capacitance @ Vr, F | 300pF @ 4V, 1MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AB, SMC | |
| Supplier Device Package | SMC | |
| Operating Temperature - Junction | -55°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | B550C-13 | |
| Related Links | B550, B550C-13 Datasheet, Diodes Incorporated Distributor | |
