Rohm Semiconductor BD7776ARFS-E2
- Mfg. Part Number
- BD7776ARFS-E2
- Manufacturer
- Rohm Semiconductor
- Product Category
- PMIC - Full, Half-Bridge Drivers
- Brief Description
- IC MOTOR DRIVER PAR 44-HTSSOP
- Datasheet Download
- BD7776ARFS-E2.pdf
Availability of BD7776ARFS-E2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.64600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of BD7776ARFS-E2, we specialize in Rohm Semiconductor all series electronic components. BD7776ARFS-E2 can be shipped within 24 hours after order. If you have any demands for BD7776ARFS-E2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- BD7776ARFS-E2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
BD7776ARFS-E2
| Internal Part Number | EIS-BD7776ARFS-E2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Full, Half-Bridge Drivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Output Configuration | Half Bridge (15) | |
| Applications | DC Motors, General Purpose | |
| Interface | Logic | |
| Load Type | Inductive | |
| Technology | - | |
| Rds On (Typ) | - | |
| Current - Output / Channel | 500mA, 1A | |
| Current - Peak Output | - | |
| Voltage - Supply | 10.8 V ~ 13.2 V | |
| Voltage - Load | - | |
| Operating Temperature | -20°C ~ 150°C (TJ) | |
| Features | - | |
| Fault Protection | Current Limiting, Over Temperature | |
| Mounting Type | Surface Mount | |
| Package / Case | 44-VSOP (0.295", 7.50mm Width) | |
| Supplier Device Package | 44-HTSSOP-A | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | BD7776ARFS-E2 | |
| Related Links | BD7776, BD7776ARFS-E2 Datasheet, Rohm Semiconductor Distributor | |
