Bourns Inc. BDW53A-S
- Mfg. Part Number
- BDW53A-S
- Manufacturer
- Bourns Inc.
- Product Category
- Transistors (BJT) - Single
- Brief Description
- TRANS NPN DARL 60V 4A
- Datasheet Download
- BDW53A-S.pdf
Availability of BDW53A-S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of BDW53A-S, we specialize in Bourns Inc. all series electronic components. BDW53A-S can be shipped within 24 hours after order. If you have any demands for BDW53A-S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- BDW53A-S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
BDW53A-S
| Internal Part Number | EIS-BDW53A-S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | TO-220 Material Declaration | |
| Standard Package | 15,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors (BJT) - Single | |
| Series | - | |
| Packaging | Tube | |
| Transistor Type | NPN - Darlington | |
| Current - Collector (Ic) (Max) | 4A | |
| Voltage - Collector Emitter Breakdown (Max) | 60V | |
| Vce Saturation (Max) @ Ib, Ic | 4V @ 40mA, 4A | |
| Current - Collector Cutoff (Max) | 500µA | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 750 @ 1.5A, 3V | |
| Power - Max | 2W | |
| Frequency - Transition | - | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-3 | |
| Supplier Device Package | TO-220 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | BDW53A-S | |
| Related Links | BDW5, BDW53A-S Datasheet, Bourns Inc. Distributor | |
BDW53A-S Details Description
