Eaton (formerly Cooper Bussmann) BK/S505-6.3A
- Mfg. Part Number
- BK/S505-6.3A
- Manufacturer
- Eaton (formerly Cooper Bussmann)
- Product Category
- Fuses
- Brief Description
- FUSE CERAMIC 6.3A 250VAC 5X20MM
- Datasheet Download
- BK/S505-6.3A.pdf
Availability of BK/S505-6.3A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of BK/S505-6.3A, we specialize in Eaton (formerly Cooper Bussmann) all series electronic components. BK/S505-6.3A can be shipped within 24 hours after order. If you have any demands for BK/S505-6.3A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- BK/S505-6.3A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
BK/S505-6.3A
| Internal Part Number | EIS-BK/S505-6.3A | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | S50x Series Non-Rohs 01/Aug/2011 | |
| PCN Design/Specification | S505 Series Select Ratings 5/Feb/2009 | |
| Standard Package | 100 | |
| Category | Circuit Protection | |
| Family | Fuses | |
| Series | S505 | |
| Packaging | Bulk | |
| Fuse Type | Cartridge, Ceramic | |
| Current Rating | 6.3A | |
| Voltage Rating - AC | 250V | |
| Voltage Rating - DC | - | |
| Response Time | Slow | |
| Package / Case | 5mm x 20mm | |
| Mounting Type | Holder | |
| Breaking Capacity @ Rated Voltage | 1.5kA | |
| Melting I²t | 197 | |
| Approvals | BSI, CCC, CSA, IMQ, SEMKO, UR, VDE | |
| Operating Temperature | - | |
| Color | - | |
| Size / Dimension | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
| DC Cold Resistance | 0.008 Ohm | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | BK/S505-6.3A | |
| Related Links | BK/S50, BK/S505-6.3A Datasheet, Eaton (formerly Cooper Bussmann) Distributor | |
BK/S505-6.3A Details Description
