Infineon Technologies BTS113A E3045A
- Mfg. Part Number
- BTS113A E3045A
- Manufacturer
- Infineon Technologies
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 60V 11.5A TO-220AB
- Datasheet Download
- BTS113A E3045A.pdf
Availability of BTS113A E3045A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of BTS113A E3045A, we specialize in Infineon Technologies all series electronic components. BTS113A E3045A can be shipped within 24 hours after order. If you have any demands for BTS113A E3045A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- BTS113A E3045A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
BTS113A E3045A
| Internal Part Number | EIS-BTS113A E3045A | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | TEMPFET® | |
| Packaging | Tape & Reel (TR) | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Logic Level Gate | |
| Drain to Source Voltage (Vdss) | 60V | |
| Current - Continuous Drain (Id) @ 25°C | 11.5A (Tc) | |
| Rds On (Max) @ Id, Vgs | 170 mOhm @ 5.8A, 4.5V | |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA | |
| Gate Charge (Qg) @ Vgs | - | |
| Input Capacitance (Ciss) @ Vds | 560pF @ 25V | |
| Power - Max | 40W | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | |
| Supplier Device Package | TO-220AB | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | BTS113A E3045A | |
| Related Links | BTS113A, BTS113A E3045A Datasheet, Infineon Technologies Distributor | |
BTS113A E3045A Details Description
