Artesyn Embedded Technologies BXB75-48D05-3V3FLJ
- Mfg. Part Number
- BXB75-48D05-3V3FLJ
- Manufacturer
- Artesyn Embedded Technologies
- Product Category
- DC DC Converters
- Brief Description
- DC/DC CONVERTER 5V 3.3V 75W
- Datasheet Download
- BXB75-48D05-3V3FLJ.pdf
Availability of BXB75-48D05-3V3FLJ
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of BXB75-48D05-3V3FLJ, we specialize in Artesyn Embedded Technologies all series electronic components. BXB75-48D05-3V3FLJ can be shipped within 24 hours after order. If you have any demands for BXB75-48D05-3V3FLJ, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- BXB75-48D05-3V3FLJ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
BXB75-48D05-3V3FLJ
| Internal Part Number | EIS-BXB75-48D05-3V3FLJ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | BXB75 | |
| Packaging | Bulk | |
| Type | Isolated Module | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 36V | |
| Voltage - Input (Max) | 75V | |
| Voltage - Output 1 | 5V | |
| Voltage - Output 2 | 3.3V | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 15A, 15A | |
| Power (Watts) - Manufacture Series | 75W | |
| Voltage - Isolation | 1.5kV (1500V) | |
| Features | Remote On/Off, OTP, OVP, SCP, UVLO | |
| Mounting Type | Through Hole | |
| Package / Case | 10-DIP Module, 1/2 Brick | |
| Size / Dimension | 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm) | |
| Operating Temperature | -40°C ~ 100°C | |
| Efficiency | 82% | |
| Power (Watts) - Max | 75W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | BXB75-48D05-3V3FLJ | |
| Related Links | BXB75-48D, BXB75-48D05-3V3FLJ Datasheet, Artesyn Embedded Technologies Distributor | |
BXB75-48D05-3V3FLJ Details Description
