Bulgin BZV03/Z0000/01
- Mfg. Part Number
- BZV03/Z0000/01
- Manufacturer
- Bulgin
- Product Category
- Power Entry Connectors - Inlets, Outlets, Modules
- Brief Description
- POLYSNAP POWER INLET MODULE
- Datasheet Download
- BZV03/Z0000/01.pdf
Availability of BZV03/Z0000/01
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.95000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of BZV03/Z0000/01, we specialize in Bulgin all series electronic components. BZV03/Z0000/01 can be shipped within 24 hours after order. If you have any demands for BZV03/Z0000/01, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- BZV03/Z0000/01 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
BZV03/Z0000/01
| Internal Part Number | EIS-BZV03/Z0000/01 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Power Entry Connectors - Inlets, Outlets, Modules | |
| Series | Polysnap® BZV | |
| Packaging | Bulk | |
| Connector Style | IEC 320-C14 | |
| Connector Type | Receptacle, Male Blades - Module | |
| Current - IEC | 10A | |
| Voltage - IEC | 250VAC | |
| Current - UL | 15A | |
| Voltage - UL | 250VAC | |
| Filter Type | Unfiltered - Commercial | |
| Fuse | No | |
| Number of Positions | 3 | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination | Quick Connect - 0.250" (6.3mm) | |
| Switch Features | Switch On-Off | |
| Features | - | |
| Fuse Holder, Drawer | - | |
| Panel Cutout Dimensions | Rectangular - 34.40mm x 48.40mm | |
| Panel Thickness | 0.039" ~ 0.118" (1.00mm ~ 3.00mm) | |
| Material Flammability Rating | UL94 V-0 | |
| Ingress Protection | - | |
| Approvals | CSA, ENEC, UL, VDE | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | BZV03/Z0000/01 | |
| Related Links | BZV03/Z, BZV03/Z0000/01 Datasheet, Bulgin Distributor | |
