KEMET C0805C109D1GACTU
- Mfg. Part Number
- C0805C109D1GACTU
- Manufacturer
- KEMET
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 1PF 100V NP0 0805
- Datasheet Download
- C0805C109D1GACTU.pdf
Availability of C0805C109D1GACTU
Available Quantity
9020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.03105
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of C0805C109D1GACTU, we specialize in KEMET all series electronic components. C0805C109D1GACTU can be shipped within 24 hours after order. If you have any demands for C0805C109D1GACTU, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- C0805C109D1GACTU Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
C0805C109D1GACTU
| Internal Part Number | EIS-C0805C109D1GACTU | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Capacitor Basics- Typical Uses for Capacitors | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 4,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | C | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 1pF | |
| Tolerance | ±0.5pF | |
| Voltage - Rated | 100V | |
| Temperature Coefficient | C0G, NP0 | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | General Purpose | |
| Ratings | - | |
| Package / Case | 0805 (2012 Metric) | |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.035" (0.88mm) | |
| Lead Spacing | - | |
| Features | - | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | C0805C109D1GACTU | |
| Related Links | C0805C10, C0805C109D1GACTU Datasheet, KEMET Distributor | |
C0805C109D1GACTU Details Description
