TDK Corporation C2012C0G1E153J085AA
- Mfg. Part Number
- C2012C0G1E153J085AA
- Manufacturer
- TDK Corporation
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 0.015UF 25V C0G 0805
- Datasheet Download
- C2012C0G1E153J085AA.pdf
Availability of C2012C0G1E153J085AA
Available Quantity
13020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.05850
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of C2012C0G1E153J085AA, we specialize in TDK Corporation all series electronic components. C2012C0G1E153J085AA can be shipped within 24 hours after order. If you have any demands for C2012C0G1E153J085AA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- C2012C0G1E153J085AA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
C2012C0G1E153J085AA
| Internal Part Number | EIS-C2012C0G1E153J085AA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | C Series General Applications SEAT, CCV, and TVCL Design Tools Guide to Replacing an Electrolytic Capacitor with an MLCC | |
| Video File | High Capacitance Capacitor Measurement Tutorial | |
| RoHS Information | RoHS Certificate-MLCC | |
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 4,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | C | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 0.015µF | |
| Tolerance | ±5% | |
| Voltage - Rated | 25V | |
| Temperature Coefficient | C0G, NP0 | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | General Purpose | |
| Ratings | - | |
| Package / Case | 0805 (2012 Metric) | |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.037" (0.95mm) | |
| Lead Spacing | - | |
| Features | - | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | C2012C0G1E153J085AA | |
| Related Links | C2012C0G1, C2012C0G1E153J085AA Datasheet, TDK Corporation Distributor | |
C2012C0G1E153J085AA Details Description
