TDK Corporation C3225X7R1E475M/5
-25.jpg)
- Mfg. Part Number
- C3225X7R1E475M/5
- Manufacturer
- TDK Corporation
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 4.7UF 25V X7R 1210
- Datasheet Download
- C3225X7R1E475M/5.pdf
Availability of C3225X7R1E475M/5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.26953
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of C3225X7R1E475M/5, we specialize in TDK Corporation all series electronic components. C3225X7R1E475M/5 can be shipped within 24 hours after order. If you have any demands for C3225X7R1E475M/5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- C3225X7R1E475M/5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
C3225X7R1E475M/5
| Internal Part Number | EIS-C3225X7R1E475M/5 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | High Capacitance Replacement C Series General Applications SEAT, CCV, and TVCL Design Tools Guide to Replacing an Electrolytic Capacitor with an MLCC | |
| Video File | High Capacitance Capacitor Measurement Tutorial | |
| RoHS Information | RoHS Certificate-MLCC | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 5,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | C | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 4.7µF | |
| Tolerance | ±20% | |
| Voltage - Rated | 25V | |
| Temperature Coefficient | X7R | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | General Purpose | |
| Ratings | - | |
| Package / Case | 1210 (3225 Metric) | |
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.087" (2.20mm) | |
| Lead Spacing | - | |
| Features | - | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | C3225X7R1E475M/5 | |
| Related Links | C3225X7R, C3225X7R1E475M/5 Datasheet, TDK Corporation Distributor | |
C3225X7R1E475M/5 Details Description
