ITT Cannon, LLC CA3106E14SA7SB14
- Mfg. Part Number
- CA3106E14SA7SB14
- Manufacturer
- ITT Cannon, LLC
- Product Category
- Circular Connectors
- Brief Description
- CONN PLUG 7POS INLINE W/SKTS
- Datasheet Download
- CA3106E14SA7SB14.pdf
Availability of CA3106E14SA7SB14
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 52.26800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CA3106E14SA7SB14, we specialize in ITT Cannon, LLC all series electronic components. CA3106E14SA7SB14 can be shipped within 24 hours after order. If you have any demands for CA3106E14SA7SB14, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CA3106E14SA7SB14 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CA3106E14SA7SB14
| Internal Part Number | EIS-CA3106E14SA7SB14 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | MIL-DTL-5015, CA-B | |
| Packaging | Bulk | |
| Connector Type | Plug, Female Sockets | |
| Number of Positions | 7 | |
| Shell Size - Insert | 14S-A7 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Fastening Type | Reverse Bayonet Lock | |
| Orientation | N (Normal) | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated | |
| Contact Finish | Silver | |
| Features | Shielded, Strain Relief | |
| Contact Finish Thickness | - | |
| Current Rating | 22A | |
| Voltage - Rated | 500VAC, 700VDC | |
| Operating Temperature | -55°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CA3106E14SA7SB14 | |
| Related Links | CA3106E1, CA3106E14SA7SB14 Datasheet, ITT Cannon, LLC Distributor | |
