Taiyo Yuden CAL45TB2R7K
- Mfg. Part Number
- CAL45TB2R7K
- Manufacturer
- Taiyo Yuden
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 2.7UH 2.5A 58 MOHM TH
- Datasheet Download
- CAL45TB2R7K.pdf
Availability of CAL45TB2R7K
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.40000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CAL45TB2R7K, we specialize in Taiyo Yuden all series electronic components. CAL45TB2R7K can be shipped within 24 hours after order. If you have any demands for CAL45TB2R7K, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CAL45TB2R7K Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CAL45TB2R7K
| Internal Part Number | EIS-CAL45TB2R7K | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | CA | |
| Packaging | Tape & Box (TB) | |
| Type | Wirewound | |
| Material - Core | - | |
| Inductance | 2.7µH | |
| Tolerance | ±10% | |
| Current Rating | 2.5A | |
| Current - Saturation | 3.5A | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 58 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -25°C ~ 105°C | |
| Frequency - Test | 7.96MHz | |
| Mounting Type | Through Hole | |
| Package / Case | Axial | |
| Size / Dimension | 0.173" Dia x 0.315" L (4.40mm x 8.00mm) | |
| Height - Seated (Max) | - | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CAL45TB2R7K | |
| Related Links | CAL45, CAL45TB2R7K Datasheet, Taiyo Yuden Distributor | |
CAL45TB2R7K Details Description
