Stackpole Electronics Inc. CB5JB12R0
- Mfg. Part Number
- CB5JB12R0
- Manufacturer
- Stackpole Electronics Inc.
- Product Category
- Through Hole Resistors
- Brief Description
- RES 12 OHM 5W 5% CERAMIC WW
- Datasheet Download
- CB5JB12R0.pdf
Availability of CB5JB12R0
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.08800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CB5JB12R0, we specialize in Stackpole Electronics Inc. all series electronic components. CB5JB12R0 can be shipped within 24 hours after order. If you have any demands for CB5JB12R0, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CB5JB12R0 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CB5JB12R0
| Internal Part Number | EIS-CB5JB12R0 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Pulse Handling Resistor Solutions | |
| RoHS Information | RoHS Compliance | |
| PCN Part Number | Global Part Number 9/Aug/2010 | |
| Standard Package | 25 | |
| Category | Resistors | |
| Family | Through Hole Resistors | |
| Series | CB | |
| Packaging | Bulk | |
| Resistance (Ohms) | 12 | |
| Tolerance | ±5% | |
| Power (Watts) | 5W | |
| Composition | Wirewound | |
| Features | Flame Proof, Moisture Resistant, Safety | |
| Temperature Coefficient | ±300ppm/°C | |
| Operating Temperature | -55°C ~ 275°C | |
| Package / Case | Axial | |
| Supplier Device Package | Axial | |
| Size / Dimension | 0.374" Square x 0.866" L (9.50mm x 22.00mm) | |
| Height | - | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CB5JB12R0 | |
| Related Links | CB5J, CB5JB12R0 Datasheet, Stackpole Electronics Inc. Distributor | |
