TDK Corporation CC45SL3FD330JYNNA
- Mfg. Part Number
- CC45SL3FD330JYNNA
- Manufacturer
- TDK Corporation
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 33PF 3KV SL RADIAL
- Datasheet Download
- CC45SL3FD330JYNNA.pdf
Availability of CC45SL3FD330JYNNA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.08232
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CC45SL3FD330JYNNA, we specialize in TDK Corporation all series electronic components. CC45SL3FD330JYNNA can be shipped within 24 hours after order. If you have any demands for CC45SL3FD330JYNNA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CC45SL3FD330JYNNA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CC45SL3FD330JYNNA
| Internal Part Number | EIS-CC45SL3FD330JYNNA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | CC45 | |
| Packaging | Bulk | |
| Capacitance | 33pF | |
| Tolerance | ±5% | |
| Voltage - Rated | 3000V (3kV) | |
| Temperature Coefficient | SL | |
| Mounting Type | Through Hole | |
| Operating Temperature | -25°C ~ 125°C | |
| Applications | General Purpose | |
| Ratings | - | |
| Package / Case | Radial, Disc | |
| Size / Dimension | 0.236" Dia (6.00mm) | |
| Height - Seated (Max) | 0.394" (10.00mm) | |
| Thickness (Max) | - | |
| Lead Spacing | 0.197" (5.00mm) | |
| Features | High Voltage, Low Dissipation Factor | |
| Lead Style | Straight | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CC45SL3FD330JYNNA | |
| Related Links | CC45SL3F, CC45SL3FD330JYNNA Datasheet, TDK Corporation Distributor | |
