Texas Instruments CD74HC4002EE4
- Mfg. Part Number
- CD74HC4002EE4
- Manufacturer
- Texas Instruments
- Product Category
- Logic - Gates and Inverters
- Brief Description
- IC GATE NOR 2CH 4-INP 14-DIP
- Datasheet Download
- CD74HC4002EE4.pdf
Availability of CD74HC4002EE4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.24650
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CD74HC4002EE4, we specialize in Texas Instruments all series electronic components. CD74HC4002EE4 can be shipped within 24 hours after order. If you have any demands for CD74HC4002EE4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CD74HC4002EE4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CD74HC4002EE4
| Internal Part Number | EIS-CD74HC4002EE4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Copper Bond Wire Revision A 04/Dec/2013 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 25 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Gates and Inverters | |
| Series | 74HC | |
| Packaging | Tube | |
| Logic Type | NOR Gate | |
| Number of Circuits | 2 | |
| Number of Inputs | 4 | |
| Features | - | |
| Voltage - Supply | 2 V ~ 6 V | |
| Current - Quiescent (Max) | 2µA | |
| Current - Output High, Low | 5.2mA, 5.2mA | |
| Logic Level - Low | 0.5 V ~ 1.8 V | |
| Logic Level - High | 1.5 V ~ 4.2 V | |
| Max Propagation Delay @ V, Max CL | 17ns @ 6V, 50pF | |
| Operating Temperature | -55°C ~ 125°C | |
| Mounting Type | Through Hole | |
| Supplier Device Package | 14-PDIP | |
| Package / Case | 14-DIP (0.300", 7.62mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CD74HC4002EE4 | |
| Related Links | CD74HC, CD74HC4002EE4 Datasheet, Texas Instruments Distributor | |
