Comchip Technology CDBA240-HF
- Mfg. Part Number
- CDBA240-HF
- Manufacturer
- Comchip Technology
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE SCHOTTKY 40V 2A DO214AC
- Datasheet Download
- CDBA240-HF.pdf
Availability of CDBA240-HF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.05248
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CDBA240-HF, we specialize in Comchip Technology all series electronic components. CDBA240-HF can be shipped within 24 hours after order. If you have any demands for CDBA240-HF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CDBA240-HF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CDBA240-HF
| Internal Part Number | EIS-CDBA240-HF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 5,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 40V | |
| Current - Average Rectified (Io) | 2A | |
| Voltage - Forward (Vf) (Max) @ If | 500mV @ 2A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 500µA @ 40V | |
| Capacitance @ Vr, F | - | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AC, SMA | |
| Supplier Device Package | DO-214AC (SMA) | |
| Operating Temperature - Junction | 125°C (Max) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CDBA240-HF | |
| Related Links | CDBA2, CDBA240-HF Datasheet, Comchip Technology Distributor | |
CDBA240-HF Details Description
