Comchip Technology CDBF0230
-Pkg.jpg)
- Mfg. Part Number
- CDBF0230
- Manufacturer
- Comchip Technology
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE SCHOTTKY 30V 200MA 1005
- Datasheet Download
- CDBF0230.pdf
Availability of CDBF0230
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.07400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CDBF0230, we specialize in Comchip Technology all series electronic components. CDBF0230 can be shipped within 24 hours after order. If you have any demands for CDBF0230, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CDBF0230 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CDBF0230
| Internal Part Number | EIS-CDBF0230 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Flat Chip Diodes | |
| RoHS Information | RoHS Declaration | |
| Standard Package | 4,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 30V | |
| Current - Average Rectified (Io) | 200mA | |
| Voltage - Forward (Vf) (Max) @ If | 500mV @ 200mA | |
| Speed | Small Signal =< 200mA (Io), Any Speed | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 30µA @ 30V | |
| Capacitance @ Vr, F | 9pF @ 10V, 1MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 1005 (2512 Metric) | |
| Supplier Device Package | 1005/SOD-323F | |
| Operating Temperature - Junction | 125°C (Max) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CDBF0230 | |
| Related Links | CDBF, CDBF0230 Datasheet, Comchip Technology Distributor | |
CDBF0230 Details Description
