Sumida Corporation CDRH4D22HPNP-100MC
- Mfg. Part Number
- CDRH4D22HPNP-100MC
- Manufacturer
- Sumida Corporation
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 10UH 1.3A 143.8 MOHM
- Datasheet Download
- CDRH4D22HPNP-100MC.pdf
Availability of CDRH4D22HPNP-100MC
Available Quantity
14461 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.52800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CDRH4D22HPNP-100MC, we specialize in Sumida Corporation all series electronic components. CDRH4D22HPNP-100MC can be shipped within 24 hours after order. If you have any demands for CDRH4D22HPNP-100MC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CDRH4D22HPNP-100MC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CDRH4D22HPNP-100MC
| Internal Part Number | EIS-CDRH4D22HPNP-100MC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Power Inductor Basics | |
| Standard Package | 1 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | CDRH4D22/HP | |
| Packaging | Cut Tape (CT) | |
| Type | - | |
| Material - Core | Ferrite | |
| Inductance | 10µH | |
| Tolerance | ±20% | |
| Current Rating | 1.3A | |
| Current - Saturation | 1.5A | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 143.8 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -40°C ~ 100°C | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.185" L x 0.185" W (4.70mm x 4.70mm) | |
| Height - Seated (Max) | 0.094" (2.40mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CDRH4D22HPNP-100MC | |
| Related Links | CDRH4D22H, CDRH4D22HPNP-100MC Datasheet, Sumida Corporation Distributor | |
CDRH4D22HPNP-100MC Details Description
