Sumida Corporation CDRH4D28CNP-470PC
- Mfg. Part Number
- CDRH4D28CNP-470PC
- Manufacturer
- Sumida Corporation
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 47UH 540MA 510 MOHM
- Datasheet Download
- CDRH4D28CNP-470PC.pdf
Availability of CDRH4D28CNP-470PC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.43520
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CDRH4D28CNP-470PC, we specialize in Sumida Corporation all series electronic components. CDRH4D28CNP-470PC can be shipped within 24 hours after order. If you have any demands for CDRH4D28CNP-470PC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CDRH4D28CNP-470PC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CDRH4D28CNP-470PC
| Internal Part Number | EIS-CDRH4D28CNP-470PC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Power Inductor Basics | |
| Standard Package | 2,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | CDRH4D28C | |
| Packaging | Tape & Reel (TR) | |
| Type | - | |
| Material - Core | Ferrite | |
| Inductance | 47µH | |
| Tolerance | ±25% | |
| Current Rating | 540mA | |
| Current - Saturation | - | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 510 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -40°C ~ 105°C | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.193" L x 0.193" W (4.90mm x 4.90mm) | |
| Height - Seated (Max) | 0.118" (3.00mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CDRH4D28CNP-470PC | |
| Related Links | CDRH4D28, CDRH4D28CNP-470PC Datasheet, Sumida Corporation Distributor | |
