Copal Electronics CFT2-2PC4-AW
- Mfg. Part Number
- CFT2-2PC4-AW
- Manufacturer
- Copal Electronics
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE DPDT .4VA 28V
- Datasheet Download
- CFT2-2PC4-AW.pdf
Availability of CFT2-2PC4-AW
Available Quantity
5320 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.42471
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CFT2-2PC4-AW, we specialize in Copal Electronics all series electronic components. CFT2-2PC4-AW can be shipped within 24 hours after order. If you have any demands for CFT2-2PC4-AW, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CFT2-2PC4-AW Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CFT2-2PC4-AW
| Internal Part Number | EIS-CFT2-2PC4-AW | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Copal - Toggle Switches | |
| Standard Package | 100 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | CFT2 | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Switch Function | On-Off-On | |
| Current Rating | 0.4VA (AC/DC) | |
| Voltage Rating - AC | 28V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Standard Round | |
| Actuator Length | 3.80mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Through Hole, Right Angle | |
| Termination Style | PC Pin | |
| Panel Cutout Dimensions | - | |
| Bushing Thread | Unthreaded | |
| Ingress Protection | - | |
| Features | Washable, Gray Actuator | |
| Actuator Material | - | |
| Electrical Life | 10,000 Cycles | |
| Operating Temperature | -40°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CFT2-2PC4-AW | |
| Related Links | CFT2-2, CFT2-2PC4-AW Datasheet, Copal Electronics Distributor | |
