Copal Electronics CHP-040TA
- Mfg. Part Number
- CHP-040TA
- Manufacturer
- Copal Electronics
- Product Category
- DIP Switches
- Brief Description
- SMD PIANO SWITCH 4 POSITION
- Datasheet Download
- CHP-040TA.pdf
Availability of CHP-040TA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.37446
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CHP-040TA, we specialize in Copal Electronics all series electronic components. CHP-040TA can be shipped within 24 hours after order. If you have any demands for CHP-040TA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CHP-040TA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CHP-040TA
| Internal Part Number | EIS-CHP-040TA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | CHP-040TA | |
| Standard Package | 500 | |
| Category | Switches | |
| Family | DIP Switches | |
| Series | CHP | |
| Packaging | Tape & Reel (TR) | |
| Circuit | SPST | |
| Number of Positions | 4 | |
| Current Rating | 100mA | |
| Voltage Rating | 6VDC | |
| Actuator Type | Piano | |
| Actuator Level | Raised | |
| Contact Material | Copper Alloy | |
| Contact Finish | Gold | |
| Height Above Board | 0.181" (4.60mm) | |
| Mounting Type | Surface Mount, Right Angle | |
| Termination Style | J Lead | |
| Pitch | 0.050" (1.27mm), Half | |
| Washable | No | |
| Features | - | |
| Body Material | Polyphenylene Sulfide (PPS) | |
| Length | 0.279" (7.10mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Mechanical Life | - | |
| Electrical Life | 1,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CHP-040TA | |
| Related Links | CHP-, CHP-040TA Datasheet, Copal Electronics Distributor | |
