TDK Corporation CKCL22X5R1H473M085AA
.jpg)
- Mfg. Part Number
- CKCL22X5R1H473M085AA
- Manufacturer
- TDK Corporation
- Product Category
- Capacitor Arrays
- Brief Description
- CAP ARRAY 0.047UF 50V X5R 0805
- Datasheet Download
- CKCL22X5R1H473M085AA.pdf
Availability of CKCL22X5R1H473M085AA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CKCL22X5R1H473M085AA, we specialize in TDK Corporation all series electronic components. CKCL22X5R1H473M085AA can be shipped within 24 hours after order. If you have any demands for CKCL22X5R1H473M085AA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CKCL22X5R1H473M085AA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CKCL22X5R1H473M085AA
| Internal Part Number | EIS-CKCL22X5R1H473M085AA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | CKC Series Array Capacitor Family | |
| RoHS Information | RoHS Certificate-MLCC | |
| Featured Product | CKC Series | |
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 | |
| Standard Package | 1 | |
| Category | Capacitors | |
| Family | Capacitor Arrays | |
| Series | CKC | |
| Packaging | Cut Tape (CT) | |
| Capacitance | 0.047µF | |
| Tolerance | ±20% | |
| Voltage - Rated | 50V | |
| Dielectric Material | Ceramic | |
| Number of Capacitors | 2 | |
| Circuit Type | Isolated | |
| Temperature Coefficient | X5R | |
| Mounting Type | Surface Mount | |
| Package / Case | 0805 (2012 Metric) | |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) | |
| Height - Seated (Max) | 0.033" (0.85mm) | |
| Ratings | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CKCL22X5R1H473M085AA | |
| Related Links | CKCL22X5R1, CKCL22X5R1H473M085AA Datasheet, TDK Corporation Distributor | |
CKCL22X5R1H473M085AA Details Description
