Bourns Inc. CM100505-2N7DL
- Mfg. Part Number
- CM100505-2N7DL
- Manufacturer
- Bourns Inc.
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 2.7NH 400MA 100 MOHM
- Datasheet Download
- CM100505-2N7DL.pdf
Availability of CM100505-2N7DL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.05320
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CM100505-2N7DL, we specialize in Bourns Inc. all series electronic components. CM100505-2N7DL can be shipped within 24 hours after order. If you have any demands for CM100505-2N7DL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CM100505-2N7DL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CM100505-2N7DL
| Internal Part Number | EIS-CM100505-2N7DL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | CM100505 Series Material Declaration | |
| PCN Obsolescence/ EOL | CM100505/CM160808 EOL 1/Jul/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 10,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | CM100505 | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Alumina | |
| Inductance | 2.7nH | |
| Tolerance | ±0.3nH | |
| Current Rating | 400mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 100 mOhm Max | |
| Q @ Freq | 8 @ 100MHz | |
| Frequency - Self Resonant | 5.5GHz | |
| Operating Temperature | -40°C ~ 100°C | |
| Frequency - Test | 100MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 0402 (1005 Metric) | |
| Size / Dimension | 0.040" L x 0.024" W (1.00mm x 0.50mm) | |
| Height - Seated (Max) | 0.024" (0.60mm) | |
| Supplier Device Package | 0402 (1005 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CM100505-2N7DL | |
| Related Links | CM10050, CM100505-2N7DL Datasheet, Bourns Inc. Distributor | |
