Fairchild Semiconductor CNY1723S
- Mfg. Part Number
- CNY1723S
- Manufacturer
- Fairchild Semiconductor
- Product Category
- Optoisolators - Transistor, Photovoltaic Output
- Brief Description
- OPTOISO 5.3KV TRANS W/BASE 6SMD
- Datasheet Download
- CNY1723S.pdf
Availability of CNY1723S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CNY1723S, we specialize in Fairchild Semiconductor all series electronic components. CNY1723S can be shipped within 24 hours after order. If you have any demands for CNY1723S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CNY1723S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CNY1723S
| Internal Part Number | EIS-CNY1723S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Isolators | |
| Family | Optoisolators - Transistor, Photovoltaic Output | |
| Series | - | |
| Packaging | Tube | |
| Number of Channels | 1 | |
| Voltage - Isolation | 5300Vrms | |
| Current Transfer Ratio (Min) | 63% @ 10mA | |
| Current Transfer Ratio (Max) | 125% @ 10mA | |
| Turn On / Turn Off Time (Typ) | 10µs, 10µs (Max) | |
| Rise / Fall Time (Typ) | 1µs, 2µs | |
| Input Type | DC | |
| Output Type | Transistor with Base | |
| Voltage - Output (Max) | 70V | |
| Current - Output / Channel | 50mA | |
| Voltage - Forward (Vf) (Typ) | 1.35V | |
| Current - DC Forward (If) (Max) | 100mA | |
| Vce Saturation (Max) | 300mV | |
| Operating Temperature | -55°C ~ 100°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 6-SMD, Gull Wing | |
| Supplier Device Package | 6-SMD | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CNY1723S | |
| Related Links | CNY1, CNY1723S Datasheet, Fairchild Semiconductor Distributor | |
CNY1723S Details Description
