ON Semiconductor CS5173GD8G
- Mfg. Part Number
- CS5173GD8G
- Manufacturer
- ON Semiconductor
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG MULT CONFIG INV ADJ 8SOIC
- Datasheet Download
- CS5173GD8G.pdf
Availability of CS5173GD8G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CS5173GD8G, we specialize in ON Semiconductor all series electronic components. CS5173GD8G can be shipped within 24 hours after order. If you have any demands for CS5173GD8G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CS5173GD8G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CS5173GD8G
| Internal Part Number | EIS-CS5173GD8G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 27/Jan/2012 | |
| Standard Package | 98 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tube | |
| Function | Step-Up, Step-Down, Step-Up/Step-Down | |
| Output Configuration | Positive or Negative | |
| Topology | Buck, Boost, Flyback, Forward Converter, SEPIC | |
| Output Type | Adjustable | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 2.7V | |
| Voltage - Input (Max) | 30V | |
| Voltage - Output (Min/Fixed) | 1.28V | |
| Voltage - Output (Max) | 40V (Switch) | |
| Current - Output | 1.5A (Switch) | |
| Frequency - Switching | 560kHz | |
| Synchronous Rectifier | No | |
| Operating Temperature | 0°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CS5173GD8G | |
| Related Links | CS517, CS5173GD8G Datasheet, ON Semiconductor Distributor | |
