ON Semiconductor CS5233-3GDF8
- Mfg. Part Number
- CS5233-3GDF8
- Manufacturer
- ON Semiconductor
- Product Category
- PMIC - Voltage Regulators - Linear
- Brief Description
- IC REG LDO 3.3V 0.5A 8SOIC
- Datasheet Download
- CS5233-3GDF8.pdf
Availability of CS5233-3GDF8
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CS5233-3GDF8, we specialize in ON Semiconductor all series electronic components. CS5233-3GDF8 can be shipped within 24 hours after order. If you have any demands for CS5233-3GDF8, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CS5233-3GDF8 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CS5233-3GDF8
| Internal Part Number | EIS-CS5233-3GDF8 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 30/Dec/2003 | |
| Standard Package | 98 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Linear | |
| Series | - | |
| Packaging | Tube | |
| Regulator Topology | Positive Fixed | |
| Voltage - Output | 3.3V | |
| Current - Output | 500mA | |
| Voltage - Dropout (Typical) | - | |
| Number of Regulators | 1 | |
| Voltage - Input | 3.3V, 4.75 V ~ 6 V | |
| Current - Limit (Min) | 550mA | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CS5233-3GDF8 | |
| Related Links | CS5233, CS5233-3GDF8 Datasheet, ON Semiconductor Distributor | |
