Stackpole Electronics Inc. CSR0402FKR130
- Mfg. Part Number
- CSR0402FKR130
- Manufacturer
- Stackpole Electronics Inc.
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 0.13 OHM 1% 1/8W 0402
- Datasheet Download
- CSR0402FKR130.pdf
Availability of CSR0402FKR130
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.03600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CSR0402FKR130, we specialize in Stackpole Electronics Inc. all series electronic components. CSR0402FKR130 can be shipped within 24 hours after order. If you have any demands for CSR0402FKR130, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CSR0402FKR130 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CSR0402FKR130
| Internal Part Number | EIS-CSR0402FKR130 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Current Sensing Resistor | |
| RoHS Information | RoHS Compliance | |
| PCN Part Number | Global Part Number 9/Aug/2010 | |
| Standard Package | 1,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | CSR | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 0.13 | |
| Tolerance | ±1% | |
| Power (Watts) | 0.125W, 1/8W | |
| Composition | Thick Film | |
| Features | Current Sense | |
| Temperature Coefficient | ±200ppm/°C | |
| Operating Temperature | -55°C ~ 155°C | |
| Package / Case | 0402 (1005 Metric) | |
| Supplier Device Package | 0402 | |
| Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) | |
| Height | 0.017" (0.42mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CSR0402FKR130 | |
| Related Links | CSR040, CSR0402FKR130 Datasheet, Stackpole Electronics Inc. Distributor | |
CSR0402FKR130 Details Description
