Riedon CSR2512C0R03F
- Mfg. Part Number
- CSR2512C0R03F
- Manufacturer
- Riedon
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 0.03 OHM 1% 3W 2512
- Datasheet Download
- CSR2512C0R03F.pdf
Availability of CSR2512C0R03F
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.15730
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CSR2512C0R03F, we specialize in Riedon all series electronic components. CSR2512C0R03F can be shipped within 24 hours after order. If you have any demands for CSR2512C0R03F, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CSR2512C0R03F Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CSR2512C0R03F
| Internal Part Number | EIS-CSR2512C0R03F | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 8,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | CSR | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 0.03 | |
| Tolerance | ±1% | |
| Power (Watts) | 3W | |
| Composition | Metal Element | |
| Features | Current Sense | |
| Temperature Coefficient | ±50ppm/°C | |
| Operating Temperature | -55°C ~ 170°C | |
| Package / Case | 2512 (6432 Metric) | |
| Supplier Device Package | 2512 | |
| Size / Dimension | 0.252" L x 0.126" W (6.40mm x 3.20mm) | |
| Height | 0.035" (0.90mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CSR2512C0R03F | |
| Related Links | CSR251, CSR2512C0R03F Datasheet, Riedon Distributor | |
CSR2512C0R03F Details Description
