Stackpole Electronics Inc. CSR2512FT50L0
.jpg)
- Mfg. Part Number
- CSR2512FT50L0
- Manufacturer
- Stackpole Electronics Inc.
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 0.05 OHM 1% 2W 2512
- Datasheet Download
- CSR2512FT50L0.pdf
Availability of CSR2512FT50L0
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.17290
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CSR2512FT50L0, we specialize in Stackpole Electronics Inc. all series electronic components. CSR2512FT50L0 can be shipped within 24 hours after order. If you have any demands for CSR2512FT50L0, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CSR2512FT50L0 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CSR2512FT50L0
| Internal Part Number | EIS-CSR2512FT50L0 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Current Sensing Resistor | |
| RoHS Information | RoHS Compliance | |
| PCN Part Number | Global Part Number 9/Aug/2010 | |
| Standard Package | 4,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | CSR | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 0.05 | |
| Tolerance | ±1% | |
| Power (Watts) | 2W | |
| Composition | Thick Film | |
| Features | Current Sense | |
| Temperature Coefficient | ±200ppm/°C | |
| Operating Temperature | -55°C ~ 155°C | |
| Package / Case | 2512 (6432 Metric) | |
| Supplier Device Package | 2512 | |
| Size / Dimension | 0.252" L x 0.126" W (6.40mm x 3.20mm) | |
| Height | 0.026" (0.65mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CSR2512FT50L0 | |
| Related Links | CSR251, CSR2512FT50L0 Datasheet, Stackpole Electronics Inc. Distributor | |
