Citizen Finedevice CSX-750PDBCT
- Mfg. Part Number
- CSX-750PDBCT
- Manufacturer
- Citizen Finedevice
- Product Category
- Programmable Oscillators
- Brief Description
- OSC 5.0V PROG CMOS STBY 50PPM
- Datasheet Download
- CSX-750PDBCT.pdf
Availability of CSX-750PDBCT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CSX-750PDBCT, we specialize in Citizen Finedevice all series electronic components. CSX-750PDBCT can be shipped within 24 hours after order. If you have any demands for CSX-750PDBCT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CSX-750PDBCT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CSX-750PDBCT
| Internal Part Number | EIS-CSX-750PDBCT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Crystals and Oscillators | |
| Family | Programmable Oscillators | |
| Series | CSX-750P | |
| Packaging | Cut Tape (CT) | |
| Type | Programmed by Digi-Key (Enter your frequency in Web Order Notes) | |
| Available Frequency Range | 1MHz ~ 125MHz | |
| Function | Standby | |
| Output | CMOS | |
| Voltage - Supply | 5V | |
| Frequency Stability | ±50ppm | |
| Operating Temperature | -20°C ~ 70°C | |
| Spread Spectrum Bandwidth | - | |
| Current - Supply (Max) | 45mA | |
| Mounting Type | Surface Mount | |
| Package / Case | 4-SMD, No Lead (DFN, LCC) | |
| Height | 0.063" (1.60mm) | |
| Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) | |
| Current - Supply (Disable) (Max) | 30mA | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CSX-750PDBCT | |
| Related Links | CSX-75, CSX-750PDBCT Datasheet, Citizen Finedevice Distributor | |
CSX-750PDBCT Details Description
