Connor-Winfield CWX823-045.0M
- Mfg. Part Number
- CWX823-045.0M
- Manufacturer
- Connor-Winfield
- Product Category
- Oscillators
- Brief Description
- OSC XO 45.000MHZ LVCMOS SMD
- Datasheet Download
- CWX823-045.0M.pdf
Availability of CWX823-045.0M
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.98750
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CWX823-045.0M, we specialize in Connor-Winfield all series electronic components. CWX823-045.0M can be shipped within 24 hours after order. If you have any demands for CWX823-045.0M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CWX823-045.0M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CWX823-045.0M
| Internal Part Number | EIS-CWX823-045.0M | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | 5.0 x 7.0mm SMD Oscillators | |
| Standard Package | 1,000 | |
| Category | Crystals and Oscillators | |
| Family | Oscillators | |
| Series | CWX823 | |
| Packaging | Tape & Reel (TR) | |
| Type | XO (Standard) | |
| Frequency | 45MHz | |
| Function | Tri-State (Output Enable) | |
| Output | LVCMOS | |
| Voltage - Supply | 3.3V | |
| Frequency Stability | ±50ppm | |
| Operating Temperature | -20°C ~ 70°C | |
| Current - Supply (Max) | 30mA | |
| Ratings | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) | |
| Height | 0.051" (1.30mm) | |
| Package / Case | 4-SMD, No Lead (DFN, LCC) | |
| Current - Supply (Disable) (Max) | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CWX823-045.0M | |
| Related Links | CWX823, CWX823-045.0M Datasheet, Connor-Winfield Distributor | |
CWX823-045.0M Details Description
