Cypress Semiconductor CY22800FXC-002A
- Mfg. Part Number
- CY22800FXC-002A
- Manufacturer
- Cypress Semiconductor
- Product Category
- Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
- Brief Description
- IC PROG CLOCK GEN 8-SOIC
- Datasheet Download
- CY22800FXC-002A.pdf
Availability of CY22800FXC-002A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CY22800FXC-002A, we specialize in Cypress Semiconductor all series electronic components. CY22800FXC-002A can be shipped within 24 hours after order. If you have any demands for CY22800FXC-002A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CY22800FXC-002A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CY22800FXC-002A
| Internal Part Number | EIS-CY22800FXC-002A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | CY22800FXC-002A Application Note | |
| Featured Product | Cypress InstaClock™ Programmable Clock Generator IC's Cypress InstaClock™ Programmable Clock Generator Kit and IC's | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers | |
| Series | - | |
| Packaging | Tube | |
| Type | Clock Generator, Fanout Distribution | |
| PLL | Yes | |
| Input | Clock, Crystal | |
| Output | LVCMOS | |
| Number of Circuits | 1 | |
| Ratio - Input:Output | 1:3 | |
| Differential - Input:Output | No/No | |
| Frequency - Max | 200MHz | |
| Divider/Multiplier | Yes/Yes | |
| Voltage - Supply | 3.14 V ~ 3.47 V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CY22800FXC-002A | |
| Related Links | CY22800, CY22800FXC-002A Datasheet, Cypress Semiconductor Distributor | |
CY22800FXC-002A Details Description
