Cypress Semiconductor CY29653AXC
- Mfg. Part Number
- CY29653AXC
- Manufacturer
- Cypress Semiconductor
- Product Category
- Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
- Brief Description
- IC CLK ZDB 8OUT 125MHZ 32TQFP
- Datasheet Download
- CY29653AXC.pdf
Availability of CY29653AXC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CY29653AXC, we specialize in Cypress Semiconductor all series electronic components. CY29653AXC can be shipped within 24 hours after order. If you have any demands for CY29653AXC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CY29653AXC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CY29653AXC
| Internal Part Number | EIS-CY29653AXC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers | |
| Series | Spread Aware™ | |
| Packaging | Tray | |
| Type | Fanout Distribution, Multiplexer, Zero Delay Buffer | |
| PLL | Yes with Bypass | |
| Input | LVPECL | |
| Output | LVCMOS | |
| Number of Circuits | 1 | |
| Ratio - Input:Output | 3:8 | |
| Differential - Input:Output | No/No | |
| Frequency - Max | 125MHz | |
| Divider/Multiplier | Yes/No | |
| Voltage - Supply | 3.135 V ~ 3.465 V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 32-TQFP | |
| Supplier Device Package | 32-TQFP (7x7) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CY29653AXC | |
| Related Links | CY296, CY29653AXC Datasheet, Cypress Semiconductor Distributor | |
