Cypress Semiconductor CY8C3246AXI-138T
- Mfg. Part Number
- CY8C3246AXI-138T
- Manufacturer
- Cypress Semiconductor
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 8BIT 64KB FLASH 100TQFP
- Datasheet Download
- CY8C3246AXI-138T.pdf
Availability of CY8C3246AXI-138T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.90860
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CY8C3246AXI-138T, we specialize in Cypress Semiconductor all series electronic components. CY8C3246AXI-138T can be shipped within 24 hours after order. If you have any demands for CY8C3246AXI-138T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CY8C3246AXI-138T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CY8C3246AXI-138T
| Internal Part Number | EIS-CY8C3246AXI-138T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Featured Product | CapSense Sensing Technology | |
| PCN Design/Specification | PSoC 3 Design Changes 14/Sep/2013 PSoC Programmer Upgrade 11/Jun/2014 | |
| PCN Assembly/Origin | Qualification Test/Finish Site 15/Dec/2013 Qualification BEOL 13/Mar/2014 Qualification Test Site 13/Mar/2014 Qualification Tape Supplier 18/Mar/2014 Qualification Copper Wire Bonds 18/Jun/2014 | |
| PCN Packaging | New Tray and TR Materials 13/Dec/2013 | |
| Standard Package | 1,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | PSOC® 3 CY8C32xx | |
| Packaging | Tape & Reel (TR) | |
| Core Processor | 8051 | |
| Core Size | 8-Bit | |
| Speed | 50MHz | |
| Connectivity | EBI/EMI, I²C, LIN, SPI, UART/USART, USB | |
| Peripherals | CapSense, DMA, LCD, POR, PWM, WDT | |
| Number of I/O | 62 | |
| Program Memory Size | 64KB (64K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | 2K x 8 | |
| RAM Size | 8K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.71 V ~ 5.5 V | |
| Data Converters | A/D 1x12b, D/A 1x8b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 100-LQFP | |
| Supplier Device Package | 100-TQFP (14x14) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CY8C3246AXI-138T | |
| Related Links | CY8C3246, CY8C3246AXI-138T Datasheet, Cypress Semiconductor Distributor | |
