Panduit D14-188B-C
- Mfg. Part Number
- D14-188B-C
- Manufacturer
- Panduit
- Product Category
- Terminals - Quick Connects, Quick Disconnect Connectors
- Brief Description
- Connector Quick Connect Receptacle 14-16 AWG 0.187" (4.75mm) Crimp
- Datasheet Download
- D14-188B-C.pdf
Availability of D14-188B-C
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of D14-188B-C, we specialize in Panduit all series electronic components. D14-188B-C can be shipped within 24 hours after order. If you have any demands for D14-188B-C, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- D14-188B-C Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
D14-188B-C
| Internal Part Number | EIS-D14-188B-C | |
| Lead Free Status / RoHS Status | ||
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 31/Dec/2012 | |
| Standard Package | 100 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - Quick Connects, Quick Disconnect Connectors | |
| Series | Pan-Term® | |
| Packaging | Bulk | |
| Terminal Type | Standard | |
| Gender | Female | |
| Tab Width | 0.187" (4.75mm) | |
| Tab Thickness | 0.020" (0.51mm) | |
| Tab Length | - | |
| Length - Overall | 0.560" (14.22mm) | |
| Termination | Crimp | |
| Wire Gauge | 14-16 AWG | |
| Insulation | Non-Insulated | |
| Mounting Type | Free Hanging (In-Line) | |
| Features | Serrated Termination | |
| Color | - | |
| Contact Material | Brass | |
| Contact Finish | Tin | |
| Insulation Diameter | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | D14-188B-C | |
| Related Links | D14-1, D14-188B-C Datasheet, Panduit Distributor | |
D14-188B-C Details Description
