Vishay/Dale D55342H07B109ERWS

D55342H07B109ERWS picture photo
Mfg. Part Number
D55342H07B109ERWS
Manufacturer
Product Category
Chip Resistor - Surface Mount
Brief Description
RES SMD 109K OHM 1% 1/4W 1206
Datasheet Download
D55342H07B109ERWS.pdf
Availability of D55342H07B109ERWS

Available Quantity

5020 Pieces

Can ship today

Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks

Marketing Price
$ 5.54400
Our Price
Quote by Email

QUANTITY



EIS Components is the stocking Distributor of D55342H07B109ERWS, we specialize in Vishay/Dale all series electronic components. D55342H07B109ERWS can be shipped within 24 hours after order. If you have any demands for D55342H07B109ERWS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
D55342H07B109ERWS Order Process
Add Parts to RFQ form
Submit RFQ
We reply within 24 hours
You confirm order
Payment
Ship out your order
Specifications of D55342H07B109ERWS
Internal Part NumberEIS-D55342H07B109ERWS
Lead Free Status / RoHS StatusContains lead / RoHS non-compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
Production Status (Lifecycle)In Production
ConditionNew & Unused, Original Sealed
PCN Assembly/OriginMultiple Devices 23/Dec/2014
EDA / CAD ModelsDownload from Accelerated Designs
Standard Package1
Category Resistors
FamilyChip Resistor - Surface Mount
SeriesMilitary, MIL-PRF-55342, RM1206
PackagingTray - Waffle
Resistance (Ohms)109k
Tolerance±1%
Power (Watts)0.25W, 1/4W
CompositionThin Film
FeaturesMilitary, Non-Inductive
Temperature Coefficient±50ppm/°C
Package / Case1206 (3216 Metric)
Supplier Device Package1206
Size / Dimension0.126" L x 0.063" W (3.20mm x 1.60mm)
Height0.033" (0.84mm)
Number of Terminations2
Failure RateR (0.01%)
Weight0.001 KG
ApplicationEmail for details
Alternative Part (Replacement)D55342H07B109ERWS
Related LinksD55342H0, D55342H07B109ERWS Datasheet, Vishay/Dale Distributor
D55342H07B109ERWS Details Description
