Vishay/Dale D55342H07B47E5RT5
.jpg)
- Mfg. Part Number
- D55342H07B47E5RT5
- Manufacturer
- Vishay/Dale
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 47.5K OHM 1% 1/4W 1206
- Datasheet Download
- D55342H07B47E5RT5.pdf
Availability of D55342H07B47E5RT5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.02724
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of D55342H07B47E5RT5, we specialize in Vishay/Dale all series electronic components. D55342H07B47E5RT5 can be shipped within 24 hours after order. If you have any demands for D55342H07B47E5RT5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- D55342H07B47E5RT5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
D55342H07B47E5RT5
| Internal Part Number | EIS-D55342H07B47E5RT5 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Multiple Devices 23/Dec/2014 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 500 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | Military, MIL-PRF-55342, RM1206 | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 47.5k | |
| Tolerance | ±1% | |
| Power (Watts) | 0.25W, 1/4W | |
| Composition | Thin Film | |
| Features | Military, Non-Inductive | |
| Temperature Coefficient | ±50ppm/°C | |
| Package / Case | 1206 (3216 Metric) | |
| Supplier Device Package | 1206 | |
| Size / Dimension | 0.126" L x 0.063" W (3.20mm x 1.60mm) | |
| Height | 0.033" (0.84mm) | |
| Number of Terminations | 2 | |
| Failure Rate | R (0.01%) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | D55342H07B47E5RT5 | |
| Related Links | D55342H0, D55342H07B47E5RT5 Datasheet, Vishay/Dale Distributor | |
