ITT Cannon, LLC DAMN11X1SNA197
- Mfg. Part Number
- DAMN11X1SNA197
- Manufacturer
- ITT Cannon, LLC
- Product Category
- D-Sub Connectors
- Brief Description
- D-Sub Connector Receptacle, Female Sockets 11 (10 + 1 Coax) Position Panel Mount, Through Hole Solder
- Datasheet Download
- DAMN11X1SNA197.pdf
Availability of DAMN11X1SNA197
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 20.95180
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DAMN11X1SNA197, we specialize in ITT Cannon, LLC all series electronic components. DAMN11X1SNA197 can be shipped within 24 hours after order. If you have any demands for DAMN11X1SNA197, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DAMN11X1SNA197 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DAMN11X1SNA197
| Internal Part Number | EIS-DAMN11X1SNA197 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | D-Sub Connectors | |
| Series | Combo D®, D*M | |
| Packaging | Bulk | |
| Connector Style | D-Sub, Combo | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 11 (10 + 1 Coax) | |
| Number of Rows | 2 | |
| Shell Size, Connector Layout | 2 (DA, A) - 11C1, 11W1 | |
| Contact Type | Coax and Signal | |
| Mounting Type | Panel Mount, Through Hole | |
| Flange Feature | Mating Side; Female Screwlock (4-40) | |
| Termination | Solder | |
| Features | Board Lock, Shielded | |
| Shell Material, Finish | Steel, Tin-Lead Plated | |
| Contact Finish | Gold | |
| Contact Finish Thickness | Flash | |
| Ingress Protection | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Voltage Rating | - | |
| Current Rating | 5A, 7.5A | |
| Housing Material | Polyester | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DAMN11X1SNA197 | |
| Related Links | DAMN11X, DAMN11X1SNA197 Datasheet, ITT Cannon, LLC Distributor | |
DAMN11X1SNA197 Details Description
