API Delevan DC1390R-224K
- Mfg. Part Number
- DC1390R-224K
- Manufacturer
- API Delevan
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 220UH 6.9A 50 MOHM TH
- Datasheet Download
- DC1390R-224K.pdf
Availability of DC1390R-224K
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.05600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DC1390R-224K, we specialize in API Delevan all series electronic components. DC1390R-224K can be shipped within 24 hours after order. If you have any demands for DC1390R-224K, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DC1390R-224K Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DC1390R-224K
| Internal Part Number | EIS-DC1390R-224K | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | DC1390R | |
| Packaging | Bulk | |
| Type | - | |
| Material - Core | Ferrite | |
| Inductance | 220µH | |
| Tolerance | ±10% | |
| Current Rating | 6.9A | |
| Current - Saturation | 9.09A | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 50 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 1kHz | |
| Mounting Type | Through Hole | |
| Package / Case | Radial | |
| Size / Dimension | 1.480" Dia (37.60mm) | |
| Height - Seated (Max) | 1.064" (27.03mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DC1390R-224K | |
| Related Links | DC1390, DC1390R-224K Datasheet, API Delevan Distributor | |
DC1390R-224K Details Description
