Diodes Incorporated DDZ3V0BSF-7
- Mfg. Part Number
- DDZ3V0BSF-7
- Manufacturer
- Diodes Incorporated
- Product Category
- Diodes - Zener - Single
- Brief Description
- DIODE ZENER 3.12V 500MW SOD323F
- Datasheet Download
- DDZ3V0BSF-7.pdf
Availability of DDZ3V0BSF-7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.01410
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DDZ3V0BSF-7, we specialize in Diodes Incorporated all series electronic components. DDZ3V0BSF-7 can be shipped within 24 hours after order. If you have any demands for DDZ3V0BSF-7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DDZ3V0BSF-7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DDZ3V0BSF-7
| Internal Part Number | EIS-DDZ3V0BSF-7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS Cert of Compliance | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Voltage - Zener (Nom) (Vz) | 3.12V | |
| Tolerance | ±3% | |
| Power - Max | 500mW | |
| Impedance (Max) (Zzt) | 120 Ohm | |
| Current - Reverse Leakage @ Vr | 50µA @ 1V | |
| Voltage - Forward (Vf) (Max) @ If | 900mV @ 10mA | |
| Operating Temperature | -65°C ~ 150°C | |
| Mounting Type | Surface Mount | |
| Package / Case | SC-90, SOD-323F | |
| Supplier Device Package | SOD-323F | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DDZ3V0BSF-7 | |
| Related Links | DDZ3V, DDZ3V0BSF-7 Datasheet, Diodes Incorporated Distributor | |
