Hirose Electric Co Ltd DF15(0.8)-50DS-0.65V(56)
-50DS-0.65V(50),-DF15(0.8)-50DS-0.65V(50).jpg)
- Mfg. Part Number
- DF15(0.8)-50DS-0.65V(56)
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine
- Brief Description
- CONN RECEPT 50POS .8MM DUAL SMD
- Datasheet Download
- DF15(0.8)-50DS-0.65V(56).pdf
Availability of DF15(0.8)-50DS-0.65V(56)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DF15(0.8)-50DS-0.65V(56), we specialize in Hirose Electric Co Ltd all series electronic components. DF15(0.8)-50DS-0.65V(56) can be shipped within 24 hours after order. If you have any demands for DF15(0.8)-50DS-0.65V(56), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DF15(0.8)-50DS-0.65V(56) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DF15(0.8)-50DS-0.65V(56)
| Internal Part Number | EIS-DF15(0.8)-50DS-0.65V(56) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine | |
| Series | DF15 | |
| Packaging | Tape & Reel (TR) | |
| Connector Type | Receptacle, Center Strip Contacts | |
| Number of Positions | 50 | |
| Pitch | 0.026" (0.65mm) | |
| Number of Rows | 2 | |
| Mounting Type | Surface Mount | |
| Features | Board Guide, Solder Retention | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 3.9µin (0.10µm) | |
| Mated Stacking Heights | 4mm, 5mm, 7mm | |
| Height Above Board | 0.118" (3.00mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DF15(0.8)-50DS-0.65V(56) | |
| Related Links | DF15(0.8)-50, DF15(0.8)-50DS-0.65V(56) Datasheet, Hirose Electric Co Ltd Distributor | |
