Renesas Electronics America DF2238RBR13WV
- Mfg. Part Number
- DF2238RBR13WV
- Manufacturer
- Renesas Electronics America
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 16BIT 256KB FLASH 112BGA
- Datasheet Download
- DF2238RBR13WV.pdf
Availability of DF2238RBR13WV
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 25.08000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DF2238RBR13WV, we specialize in Renesas Electronics America all series electronic components. DF2238RBR13WV can be shipped within 24 hours after order. If you have any demands for DF2238RBR13WV, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DF2238RBR13WV Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DF2238RBR13WV
| Internal Part Number | EIS-DF2238RBR13WV | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Electromagnetic Noise Reduction Techniques Part 1 | |
| Design Resources | Development Tool Selector | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | H8® H8S/2200 | |
| Packaging | Tray | |
| Core Processor | H8S/2000 | |
| Core Size | 16-Bit | |
| Speed | 13MHz | |
| Connectivity | I²C, SCI, SmartCard | |
| Peripherals | POR, PWM, WDT | |
| Number of I/O | 72 | |
| Program Memory Size | 256KB (256K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 16K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.2 V ~ 3.6 V | |
| Data Converters | A/D 8x10b; D/A 2x8b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 112-LFBGA | |
| Supplier Device Package | 112-LFBGA (10x10) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DF2238RBR13WV | |
| Related Links | DF2238, DF2238RBR13WV Datasheet, Renesas Electronics America Distributor | |
DF2238RBR13WV Details Description
