TE Connectivity Deutsch Connectors DL64R24-61P7-6117-LC
- Mfg. Part Number
- DL64R24-61P7-6117-LC
- Manufacturer
- TE Connectivity Deutsch Connectors
- Product Category
- Circular Connectors - Housings
- Brief Description
- CONN HSG RCPT JAM NUT 61POS PIN
- Datasheet Download
- DL64R24-61P7-6117-LC.pdf
Availability of DL64R24-61P7-6117-LC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 68.30980
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DL64R24-61P7-6117-LC, we specialize in TE Connectivity Deutsch Connectors all series electronic components. DL64R24-61P7-6117-LC can be shipped within 24 hours after order. If you have any demands for DL64R24-61P7-6117-LC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DL64R24-61P7-6117-LC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DL64R24-61P7-6117-LC
| Internal Part Number | EIS-DL64R24-61P7-6117-LC | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors - Housings | |
| Series | MIL-C-83723 Series III | |
| Packaging | Bulk | |
| Connector Type | Receptacle for Male Contacts | |
| Number of Positions | 61 | |
| Shell Size - Insert | 24-61 | |
| Shell Size, MIL | - | |
| Contact Type | Crimp | |
| Contact Size | 20 | |
| Mounting Type | Panel Mount, Bulkhead - Front Side Nut | |
| Fastening Type | Bayonet Lock | |
| Orientation | 7 | |
| Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Features | - | |
| Note | Contacts Not Provided | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DL64R24-61P7-6117-LC | |
| Related Links | DL64R24-61, DL64R24-61P7-6117-LC Datasheet, TE Connectivity Deutsch Connectors Distributor | |
DL64R24-61P7-6117-LC Details Description
