NKK Switches DLB2141W01-01B
- Mfg. Part Number
- DLB2141W01-01B
- Manufacturer
- NKK Switches
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON DPDT 5A 125V
- Datasheet Download
- DLB2141W01-01B.pdf
Availability of DLB2141W01-01B
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DLB2141W01-01B, we specialize in NKK Switches all series electronic components. DLB2141W01-01B can be shipped within 24 hours after order. If you have any demands for DLB2141W01-01B, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DLB2141W01-01B Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DLB2141W01-01B
| Internal Part Number | EIS-DLB2141W01-01B | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | DLB | |
| Packaging | Bulk | |
| Type | Standard | |
| Circuit | DPDT | |
| Switch Function | On-Mom | |
| Current Rating | 5A (AC), 3A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Square, Button | |
| Color - Actuator/Cap | White | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Rear | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Features | - | |
| Panel Cutout Dimensions | Circular - 12.50mm Dia | |
| Operating Temperature | -10°C ~ 50°C | |
| Mechanical Life | 30,000 Cycles | |
| Electrical Life | 10,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DLB2141W01-01B | |
| Related Links | DLB2141, DLB2141W01-01B Datasheet, NKK Switches Distributor | |
DLB2141W01-01B Details Description
