NKK Switches DLB2145W01-G1C-S
- Mfg. Part Number
- DLB2145W01-G1C-S
- Manufacturer
- NKK Switches
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON DPDT 5A 125V
- Datasheet Download
- DLB2145W01-G1C-S.pdf
Availability of DLB2145W01-G1C-S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DLB2145W01-G1C-S, we specialize in NKK Switches all series electronic components. DLB2145W01-G1C-S can be shipped within 24 hours after order. If you have any demands for DLB2145W01-G1C-S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DLB2145W01-G1C-S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DLB2145W01-G1C-S
| Internal Part Number | EIS-DLB2145W01-G1C-S | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | DLB | |
| Packaging | Bulk | |
| Type | Standard, Illuminated | |
| Circuit | DPDT | |
| Switch Function | On-On | |
| Current Rating | 5A (AC), 3A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Square, Button | |
| Color - Actuator/Cap | Red | |
| Illumination Type, Color | Incandescent, Red | |
| Illumination Voltage (Nominal) | 14 VAC | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Features | - | |
| Panel Cutout Dimensions | Square - 22.20mm² | |
| Operating Temperature | -20°C ~ 50°C | |
| Mechanical Life | 30,000 Cycles | |
| Electrical Life | 10,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DLB2145W01-G1C-S | |
| Related Links | DLB2145W, DLB2145W01-G1C-S Datasheet, NKK Switches Distributor | |
