Crydom DR2260A30U
- Mfg. Part Number
- DR2260A30U
- Manufacturer
- Crydom
- Product Category
- Solid State Relays
- Brief Description
- RELAY SSR 600V 30A DIN RAIL
- Datasheet Download
- DR2260A30U.pdf
Availability of DR2260A30U
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 52.17500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DR2260A30U, we specialize in Crydom all series electronic components. DR2260A30U can be shipped within 24 hours after order. If you have any demands for DR2260A30U, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DR2260A30U Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DR2260A30U
| Internal Part Number | EIS-DR2260A30U | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 20 | |
| Category | Relays | |
| Family | Solid State Relays | |
| Series | DR22 | |
| Packaging | Bulk | |
| Circuit | SPST-NO (1 Form A) | |
| Output Type | AC, Zero Cross | |
| On-State Resistance | - | |
| Load Current | 30A | |
| Voltage - Input | 90 ~ 280VAC/DC | |
| Voltage - Load | 48 ~ 600 V | |
| Mounting Type | DIN Rail | |
| Termination Style | Screw Terminal | |
| Package / Case | SSR with Integrated Heat Sink | |
| Supplier Device Package | - | |
| Relay Type | Relay | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DR2260A30U | |
| Related Links | DR226, DR2260A30U Datasheet, Crydom Distributor | |
DR2260A30U Details Description
